YSTRAL X batch dispersers
YSTRAL X-Batch Disperser

High shearing rate with the rotor-stator principle

ystral X-batch Disperser dispersing

YSTRAL X-Batch Disperser

Dispersion according to the rotor-stator principle

YSTRAL high-performance dispersing machines work on the rotor-stator principle with high shear gradients. The extreme fine distribution of solids (suspensions) and liquids (emulsions) in introduced liquid media is achieved by perfectly coordinated interaction of different comminution processes. The high-precision dispersing tools are individually adapted to the respective task.

Advantages of the YSTRAL X-Batch Disperser

  • Robust rotor-stator tools with a narrow radial gap ensure high shear gradients
  • The centrifugal force in the rotor simultaneously causes circulation of the container contents
  • Impact and high-frequency pressure-relaxation processes achieve a strong dispersing effect is achieved
  • Solid components and/or drops are reliably comminuted and distributed homogeneously
  • Different rotor-stator pairings allow adaptation to the corresponding application

  • Batch dispersion directly in the container
  • No rotating container contents - no dripping and no air entry
  • No free-running shaft and no free-running dispersing tools
  • Tank installation from above, below or laterally or operation on the lifting frame

Functionality of the YSTRAL X-Batch Disperser

  • Robust rotor-stator tools with a narrow radial gap ensure high shear gradients.
  • Impact and high-frequency pressure-relaxation processes achieve a strong dispersing effect is achieved.
  • Solid components and/or drops are reliably comminuted and distributed homogeneously.
ystral X-batch Disperser dispersing
ystral X-batch Disperser dispersing
ystral X-batch Disperser dispersing
ystral X-batch Disperser dispersing

Technical data

Power: 1.5 – 55 kW
Voltage: 230 / 400 V, 50 Hz, custom voltages possible
Speed: 1.500 / 3.000 min-1, stepless up to 3,600 min-1 with frequency converter
Seal: Lip seal, mechanical seal single or double depending on application condition
Options: Explosion-resistant design, certificate, qualifications
diving part: Stainless steel 1.4404 (AISI 316 L), special material
Bearing flange: Aluminium coated, 1.4404 (AISI 316 L)
Circumferential speed: 10 – 54 m/s
Power: 1.5 – 55 kW
Voltage: 230 / 400 V, 50 Hz, custom voltages possible
Speed: 1.500 / 3.000 min-1, stepless up to 3,600 min-1 with frequency converter
Seal: Lip seal, mechanical seal single or double depending on application condition
Options: Explosion-resistant design, certificate, qualifications
diving part: Stainless steel 1.4404 (AISI 316 L), special material
Bearing flange: Aluminium coated, 1.4404 (AISI 316 L)
Circumferential speed: 10 – 54 m/s
